High Speed Rotor Full Modification Machine , 2700/Min Powder Coating Machine

High Speed Rotor Full Modification Machine , 2700/Min Powder Coating Machine
High Speed Rotor Full Modification Machine , 2700/Min Powder Coating Machine

Large Image :  High Speed Rotor Full Modification Machine , 2700/Min Powder Coating Machine

Product Details:

Place of Origin: CHINA
Brand Name: HK
Certification: ISO CE
Model Number: 600

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: nude and plywood box
Delivery Time: 30 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 2000 Set Per Year
Detailed Product Description
Capacity: 1500kg-3500kg Powder Fineness: 400-6000mesh
Main Machine Power: 111kw Spindle Speed: 2700r/min
High Light:

powder coating production equipment


modification machine


2700/Min Powder Coating Machine

High Speed Rotor Calcium Carbonate Coating Machine With Full Modification:


Amount of Modifier Used in the High Speed Rotor Calcium Carbonate Coating Machine


      When the coating machine works, the utilization rate of modifier is high, and the powder modification effect is very good, but the dosage of the agent is not lower than that of ordinary equipment. There are two main reasons for this seemingly abnormal phenomenon: firstly, the powder and the modifier are fully mixed and modified, so that the possibility of individual powder particles being coated is increased, and the dosage of the agent is increased; secondly, the powder is depolymerized by the high-speed rotor in the main machine, so that some powder agglomeration particles are depolymerized and the particle size becomes finer, thereby increasing the specific surface area of the powder and correspondingly increasing the dosage of the agent.

     For different powders, the amount of modifier used in the coating machine is also different, generally 0.3% to 1.0% of the quality of the modified powder. The SLG type modification machine has the functions of modification and depolymerization and dispersion, which reduces the probability of the powder coated particles agglomerated by the agent, improves the coating rate of the individual powder particles, and the modified product can fully reflect the modified filler.

      Functional effects: in the production of products, the modified powder as a filler shows good dispersion and processability of the organic matrix medium, and allows the product to obtain the expected good physical and chemical properties, such as good mechanical strength, electrical insulation, and corrosion resistance, flame retardancy, etc.



     Calcium carbonate is a kind of versatile inorganic filler, because there are many hydroxyl groups on the surface that can easily absorb water and make powder hydrophilic and oleophobic. The interface formed by the matrix is poor in adhesion. In order to make full use of calcium carbonate powder, powder should be made be as small as possible, which has the disadvantages: easy to reunite because of the extra large surface and surface property. After reunion, the powder cannot be used properly. So it is necessary to do calcium carbonate powder surface modification.


Special Features of Calcium Carbonate Coating Machine


1. 100% of the surface of all powder particles can be coated with modifier ( with special spray technology)

2. Higher powder coating rate and activated rate

3. No leakage of dust; auto control of material feeding by PLC system; easy operation

4. Continuous production, higher productivity; Running smoothly; less power consumption


Components of Calcium Carbonate Coating Machine


This equipment consists of 1. powder feeding device 2. modifier metering device 3. Spraying device 4. coating chamber 5. pneumatic system 6. pulse-jet collector 7. electric control cabinet



Technical Data of Calcium Carbonate Coating Machine:


Technical Data


Main Machine Power(KW) Spindle Speed(R/Min)



Blower Power(KW)

Dusting Area


300 55.5 4500 500-2000 5.5 60
600 111 2700 1500-3500 22 150
900 225 2000 3000-7500 45 300


Calcium Carbonate Coating Machine
