132KW Ultrafine Grinding Mill With 26 / 28 Rollers

132KW Ultrafine Grinding Mill With 26 / 28 Rollers
132KW Ultrafine Grinding Mill With 26 / 28 Rollers

Large Image :  132KW Ultrafine Grinding Mill With 26 / 28 Rollers

Product Details:

Place of Origin: CHINA
Brand Name: HK
Certification: ISO CE
Model Number: 219

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: 80000-150000USD
Packaging Details: Plywood box and Nude
Delivery Time: 45-60 DAYS
Payment Terms: L/C, T/T, D/A
Supply Ability: 1000 SET PER YEAR
Detailed Product Description
Ring: 4 Layers Roller: 26 Or 28
Mill Power: 132KW Blower: 75KW
Fineness: 400-2500mesh Output: 1-10T/H
High Light:

132KW Ultrafine Grinding Mill

,

28 Rollers Ultrafine Grinding Mill

,

26 Rollers Ultrafine Powder Grinding Mill

Low wear rate ultra-fine grinding mill with higher output and lower power consumption





      The ultra-fine grinding mill is a newly developed ultra-fine grinding equipment which has accumulated many years of production and R&D experience. , The following stone can be ground by ultra-fine grinding mill: dolomite, potassium feldspar, bentonite, kaolin, graphite, carbon and other non-metallic minerals with a Mohs hardness of 7 or less and a humidity of less than 6%. Ultra-fine grinding mill is a truly efficient, energy-saving, ultrafine grinding equipment that is especially suitable for deep processing of non-metallic minerals.



     For the selection of grinding mills, customers need to know what materials they want to grind, what fineness they need, and how many ton they need per hour. After knowing these specific needs, they can choose equipment that better meets their own production needs.



1. Higher fineness, higher output, lower energy consumption and lower investment. The grinding capacity of ultra-fine grinding mill is more than double that of similar equipment.



2. The grinding system is perfect, which can realize the two processes of superfine grinding and superfine classification at the same time.



3. The fineness of the finished product can be adjusted arbitrarily between 0.04-0.005mm (400-2500 mesh), and the produced products with different fineness can better meet the market demand and improve the competitiveness of enterprises.



4. Environment-friendly production: the equipment has lower operating noise, higher dust removal efficiency and no dust pollution.



5. Equipment installation is very convenient, no large-scale civil engineering is required, and the equipment can be used and put into production after installation.



6. The equipment runs smoothly and has reliable performance. It can be continuously and normally produced. The product fineness classification accuracy is high and the product quality is good.



7. Low wear rate: The wearing parts are made of special wear-resistant materials, which can prolong the service life



Technical Data of ultra-fine grinding mill:



Mesh 21 Rollers 28 Roller
D97 Output Power Output Power
Kg/h kw/h Kg/h kw/h
300 3000-3500 43-50 5000-5500 43
800 2500-2800 54-60 3200-3800 62
1250 1500-1800 84-101 2300-2500 103
1500 1000-1300 116-152 2000-2300 118
2000 650-750 202-233 1500-1800 158
2500 600-650 233-253 1200-1300 197
Total Power 152kw 237kw




ultra-fine grinding mill

ultra-fine grinding mill
